C6260 Ordinary Lathe Machine Ordinary Lathe Center Lathe Machine

  • >=1 Sets
    $9,860.00
Max. Swing Diameter (mm):
600mm
Spindle bore:
82mm
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 100 >100
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Max. Swing Diameter (mm):
600
Max. Length of Workpiece (mm):
2015
Range of Spindle Speed(r.p.m):
20 - 1600 r.p.m
Machining Capacity:
Medium duty
Spindle Bore(mm):
82
Width of bed (mm):
300
Max. Turned Length (mm):
2015 mm
Type:
HORIZONTAL
Spindle Motor Power(kW):
4
Place of Origin:
Shandong, China
Brand Name:
DTMC
Model Number:
C6260
Voltage:
380V
Dimension(L*W*H):
2250*1130*1540
Certification:
CE
Weight (KG):
3490 KG
Warranty:
1 YEAR
After-sales Service Provided:
Online support, Video technical support, Free spare parts
Key Selling Points:
Multifunctional
Applicable Industries:
Machinery Repair Shops, Manufacturing Plant, HOME USE, Construction works , Energy & Mining, Advertising Company
After Warranty Service:
Online support, Spare parts
Local Service Location:
Egypt, canada, turkey, UNITED KINGDOM, United States, ITALY, france, GERMANY, VIET NAM, philippines, brazil, peru, SAUDI ARABIA, indonesia, pakistan, INDIA, Mexico, RUSSIA, spain, Thailand, japan, malaysia, Australia, Morocco, kenya, argentina, CHILE, UAE, Colombia, algeria, Sri Lanka, Romania, BANGLADESH, south africa, KAZAKHSTAN, UKRAINE, kyrgyzstan, NIGERIA, uzbekistan, Tajikistan
Showroom Location:
Egypt, canada, turkey, UNITED KINGDOM, United States, ITALY, france, GERMANY, VIET NAM, philippines, brazil, peru, SAUDI ARABIA, indonesia, pakistan, INDIA, Mexico, RUSSIA, spain, Thailand, Morocco, kenya, argentina, CHILE, UAE, Colombia, algeria, Sri Lanka, Romania, BANGLADESH, south africa, KAZAKHSTAN, UKRAINE, kyrgyzstan, NIGERIA, uzbekistan, Tajikistan, japan, malaysia, Australia
Marketing Type:
Ordinary Product
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 YEAR
Core Components:
Bearing, GEAR
Max.Swing over bed:
600mm
Swing over crose slide:
399mm
Height of center:
300mm
Distance between centers:
1515mm/2015mm
Width of bed:
400mm
Max. section of cutting tool:
25mm*25mm
Total travel of cross slide:
358mm
Total travel of top slide:
200mm
Spindle bore:
82mm
Total travel of tailstock quill:
180mm
Supply Ability
Supply Ability:
100 Set/Sets per Day
Packaging & Delivery
Packaging Details
Standard export package,custom suffocating free.
Port
Qingdao Shanghai
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 100 >100
Est. Time(days) 30 To be negotiated
Video Description
Products Description
Product Paramenters
Whole piece casting iron foot stand. 400mm width of bedway,high rigidity,stable precision. 11KW(15PH) main motor for optional.
Model
C6260×1500
C6260×2000
Swing over bed
ø600mm(23 10/16")
Swing over cross slide
ø399mm(15 3/4")
Swing in gap(D×W)
835mm×218mm(D1-8)/
835mm×240mm(A1-8)
Height of center
300mm(11 13/16")
Distance between centers
1515mm/2015mm
Width of bed
400mm(15 3/4")
Max. section of cutting tool
25mm×25mm(1"×1")
Total travel of cross slide
358mm(14 1/8")
Total travel of top slide
200mm(7 7/8")
Spindle bore
ø82mm(3 1/4")
Spindle nose
D1-8 or A1-8
Spindle morse taper in nose,in sleeve
ME90/M.T.#5
Spindle speeds number
12
Spindle speeds range
20-1600 R.P.M
Leadscrew diameter&
thread
40mm(1 9/16")×4 T.P.I or
pitch 6mm
Threads imperial pithches
4-112(50 NOS)
Threads metric pithches
0.25-7(24 NOS)
Diametral pitches DP/DP
4-112(50 NOS)
Diametral pitches MP/MP
0.25-14(34 NOS)
Longitudinal feeds(imperial/metric)
0.0011"-0.0316"(50Nos)/0.01mm-0.286mm(50Nos)
Cross feeds(imperial/metric)
0.00024"-0.0068"(50Nos)/0.01mm-0.286mm(50Nos)
Total travel of tailstock quill
180mm(7 5/64")
Tails stock quill
ø75mm(2 61/64")
Taper tailstock quill
M.T.#5
Spindle drive motor
10.0HP
Coolant pump motor
1/8HP(0.1KW)
Machine dimension
114"×38"×52"/134"×38"×52"
Packing dimension
118"×43"×71"/138"×43"×71"
N.W
2820KG/3080KG
G.W
3180KG/3490KG
